Timberline 850 Support Guide

What's in This Article?

Information on Traeger's Timberline 850 grill.



TFB85WLE USA & Canada Active



Owner's Manual





Below are links help you get the most out of your Timberline 850, whether it's learning best-use practices or how to resolve common issues.

Operating Your Timberline 850 How to start/ignite your Timberline 850
How to shut down/turn off your Timberline 850
How to season your Timberline 850
Cleaning your Timberline 850
Navigating your WiFIRE controller
Connecting to WiFi & App Pairing How to pair a WiFIRE grill: iPhone | Android
How to update your grill's firmware
Grill won't connect to WiFi/Grill won't pair
Error Messages & Notifications WiFIRE Grill Notifications
Temperature Management WiFIRE Grill Running too Hot
WiFIRE Grill Running too Cool
Temperature Swings



Controller WiFi Controller
Startup Procedure Closed-Lid Startup
Assembled Dimensions

46" L x 28" W x 51" H

116.84cm L x 71.12cm W x 129.54cm H

Assembled Weight

208 lbs

9435 kg

Package Dimensions

43" L x 31" W x 22.5 H

109.22cm L x 78.74cm W x 57.15cm H

Package Weight

233 lbs

105.69 kg

Main Grate Dimensions

22" L x 16.5" D

55.88cm L x 41.91cm D

Main Grilling Area

363 sq. in.

2341.93 sq. cm

2nd Grate Dimensions

22" L x 14" D

55.88cm L x 35.56cm D

2nd Grate Grilling Area

308 sq. in.

1987.1 sq. cm

3rd Grate Dimensions

22" L x 9" D

55.88cm L x 22.86cm D

3rd Grate Grilling Area

198 sq. in.

1277.42 sq. cm

Total Grilling Area

869 sq. in.

5606.44 sq. cm

Barrel Size


55.88 cm

Hopper Capacity

24 lbs

10.89 kg

Maximum Temperature 500°F  260°C
Meat Probe Count 1
BTUs 18,000
Side Shelf Stainless with Hooks
Exhaust System Downdraft
Pellet Evacuation Door
Pellet Sensor Yes; Included
Super Smoke Yes





Bottom Shelf BAC378: Bottom Shelf Pro Series 22
Cover BAC359: Traeger Timberline 850 Grill Cover - Full Length
Cutting Board BAC406: Magnetic Bamboo Cutting Board
Drip Tray Liner BAC522: Traeger Drip Tray Liners - 5 Pack - Timberline 850
Grease Trough Liner BAC404: Traeger Timberline Grease Pan Liner - 5 Pack
Meat Probe BAC431: Traeger Replacement Meat Probe - 2 Pack
Pellet Bucket BAC637: Traeger StayDry Pellet Bin & Lid



Prior to purchasing replacement parts, we suggest contacting Customer Support to confirm the part you want is indeed the part you need. If you want to use your grill's warranty you will need to contact Customer Support.

Hyperlinked SKUs are available to purchase on Traeger.com. SKUs without hyperlinks require contacting Customer Support to order.



Auger Auger Assembly KIT0426: Auger Assembly
Auger Motor KIT0577: DC Auger Motor Kit
Backpack Backpack Cover KIT0492: Backpack Cover: D2 Timberline 850
Controller Controller KIT0486: WiFi Controller: D2 Timberline
Controller Knob KIT0580: WiFi Controller Knob
Cutting Board KIT0221: Cutting Board Accessory: Timberline
Drip Tray KIT0491: Traeger Drip Tray: D2 Timberline 850

Induction Fan

KIT0481: Traeger D2 Fan Motor Kit for Timberline

Firepot and Hot Rod Assembly

KIT0382: Hot Rod/Firepot Combo Kit - Ironwood & D2 Timberline
Grates Main Grate KIT0219: Lower Stainless Grill Grate: Timberline 850
Middle Grate KIT0218: Middle Stainless Grill Grate: Timberline 850
Upper Grate  KIT0220: Upper Stainless Grill Grate: Timberline 850
Grease Drainage Grease Drain Chute KIT0498: Grease Drain Chute: D2 Timberline
Grease Drawer KIT0475: Grease Drawer Assembly
Grease Pan Cover  KIT0499: Grease Pan Cover: D2 Timberline
Heat Baffle KIT0450: Heat Baffle
Hopper  Hopper Access Panel KIT0483: Hopper Bottom Cover: D2 Timberline
Hopper-Burner Assembly KIT0493: Hopper Burner Assembly: Timberline 850
Hopper Lid KIT0208: Hopper Lid Kit: Timberline
Hopper Pellet Guard KIT0479: Hopper Guard: D2 Timberline
Pellet Cleanout Door KIT0494: Pellet Dump Door: Timberline 850, 1300
Inner Walls Inner Left Wall KIT0487: Inner Insulation Wall Left D2 Timberline
Inner Right Wall KIT0488: Inner Insulation Wall Right D2 Timberline
Legs Front Left Leg KIT0471: Front Left Caster Leg: D2 Timberline
Front Right Leg KIT0472: Front Right Wheel Leg: D2 Timberline
Rear Left Leg KIT0470: Rear Left Caster Leg: D2 Timberline
Rear Right Leg KIT0473: Rear Right Wheel Leg: D2 Timberline
Leg Brace KIT0150: Leg Brace: Sawhorse Legs
Lid Lid Assembly KIT0490: Door Assembly: D2 Timberline 850
Lid Gasket KIT0222: Door Gasket: Timberline 850
Lid Handle KIT0435: Door Handle: Ironwood 650, Timberline 850
Probe Grommet BRN249: Silicone Probe Grommet
Lower Heat Shield KIT0489: Lower Heat Shield: Timberline 850
Meat Probe BAC289: Meat Probe 1 (Black)
Pellet Sensor KIT0497: Pellet Sensor: D2 Timberline
Power Parts On/Off Switch KIT0358: Traeger On/Off Switch: Ironwood
Power Brick KIT0480: Traeger Power Brick Replacement Kit
Power Cord KIT0257: Traeger D2 Nema Power Cord
Shelves Front Shelf KIT0212: Front Shelf: AC Timberline 850
Side Shelf KIT0403: Side Shelf Ironwood, DC Timberline
Thermocouple Thermocouple KIT0217: Traeger Thermocouple Probe Kit for Timberline
Thermocouple Clip KIT0251: Thermocouple Clip: Timberline
Wheels Caster Wheel Requires full leg replacement
Hubcap KIT0496: Hubcap: Timberline
Stationary Wheel KIT0213: Timberline Large Wheel with Hubcap
WiFi Antenna KIT0495: WiFi Antenna Kit
