Woodridge Elite Support Guide

What's in This Article?

Elite Lifestryle.png

Your support guide for the Woodridge Elite Traeger grill.

Get notified when the Woodridge Elite will be available to purchase on traeger.com here:

MODEL NUMBER COUNTRY AVAILABILITY
TFC97XLH USA & Canada Coming Spring 2025

Woodridge Elite.png

Documentation

DOCUMENT LANGUAGE AMENDMENTS
Owner's Manual

English
French Canadian


Assembly Guide

English
French Canadian





Specs

Elite Dimensions.png

Controller Dot-Matrix LED WiFIRE Controller
Color Black
Assembled Dimensions

67" L x 27" D x 47" H

Assembled Weight

220.5 lbs

Package Dimensions

50" L x 30" D x 24" H

Package Weight

385 lbs

Main Grate Dimensions

31.8" L x 18.4" D

Main Grilling Area

585 sq. in

2nd Grate Dimensions 31.8" L x 12.1" D
2nd Grate Grilling Area 384 sq. in
Total Grilling Area

970 sq. in.

Hopper Capacity

24 lbs

Meat Probe Count 2
Side Shelf Yes, with electric side burner
Exhaust System Downdraft
Pellet Evacuation Trapdoor
Startup Procedure Closed-Lid
Pellet Sensor Yes
Super Smoke Yes
WiFIRE Yes



Using Your Woodridge Elite

Assembly

Using Your Grill's Controller

See also, Using a Woodridge Series Controller.

Cleaning Your Grill



Troubleshooting Your Grill

Woodridge Errors



Replacement Parts

Elite Service Parts.png

1 Upper Grill Grate 10

Electric Side Burner

Now you can simplify your meal preparation by doing it all in one
place. Create tasty sides and added dishes to go with your wood-fired
masterpieces. With the Traeger® Side Burner, you can sear, simmer,
sauté, fry, and boil food – right at your grill!

2 Lower Grill Grate  11 P.A.L. Pop-And-Lock Accessory Rail
Coming from the Timberline, Ironwood, and Flatrock. The P.A.L. rail will hold all the standard P.A.L. Accessories aside from the folding front shelves for Timberline and Ironwood. This allows the customer to make this grill their own by adding the accessories they will use each and every cook.
3 ModiFIRE Grill Grate 12

Cabinet

Extra storage for your grill accessories

4 Drip Tray
The drip tray for the Woodridge grill is designed to be placed in one direction to allow grease to flow into the grease drain. The size allows ample coverage to allow for large cooks.
13 Lid Handle
The Woodridge lid handle includes x2 handle offset pieces, each with its own Mica gasket to reduce heat transfer from the barrel to the handle.
5 Heat Baffle
Like previous grills, the heat baffle will direct the flow of the heat from the firepot throughout the grill.
14 Lid
Taking inspiration from newer grills like the Timberline and Ironwood, the Woodridge's new streamlined lid keeps smoke moving within the grill for convection cooking.
6

Ember Shield (aka Ash Cap)
The ember shield, also called the ash cap is new with the Woodridge Series. It sits atop the grease chute inside the grill to prevent sparks and embers from entering the Grease & Ash Keg.

15 WiFIRE Controller
The Woodridge controller has a new look. This WiFIRE-enabled Dot-Matrix controller displays information differently from previous WiFIRE-enabled models.
7 Grease Chute
This is a removable piece of the grease management system. The shape of this piece allows for placement in one way only, which will prevent improper placement. It is removable for easy cleanup.
16 Auger Box
This all-new component is the biggest difference in serviceability that differentiates the Woodridge Series from Traeger's previous lines of grills. This single component houses the grill's primary mechanical components: the auger, auger motor, hot rod, Induction Fan, and control board
8 EZ-Clean Grease & Ash Keg
The same EZ-Clean system from the Flatrock is in use on the Woodridge. This makes cleaning out the keg fast and easy. The same liners for the Flatrock EZ-Clean Grease + Ash Keg will fit.
17 P.A.L. Compatible Utility Rack
9 Wired Meat Probe
The same, trusted wired meat probe included with most Traeger pellet grills.
18 Caster Wheels

Grill Body Service Parts

PART SKU REPLACEMENT INSTRUCTIONS
Backsplash Backsplash KIT0977 Replacement Instructions
Backsplash Hooks KIT0960 Replacement Instructions
Cabinet Bottom Panel: Hopper Side KIT0994
Bottom Panel: Shelf Side
Bottom Panel Support Bracket KIT1022
Door: Hopper Side KIT0988 Replacement Instructions
Door: Shelf Side KIT0989 Replacement Instructions
Leg: Front, Hopper Side KIT0966
Leg: Rear, Hopper Side KIT0932
Power Cable Routing Clips KIT0924
Rear Panel: Hopper Side KIT0992
Rear Panel: Shelf Side KIT0993
Rear Panel Trim KIT1023
Side Panel: Hopper Side KIT0990
Side Panel: Shelf Side KIT0991
Upper Cabinet Doorstop Panel w/Door Magnets KIT0931
Hopper  Hopper Cavity & Pellet Sensor KIT0981
Hopper Lid KIT0953
Hopper-Grill Body Bracket KIT0943
Heritage Trim Band KIT0967 Replacement Instructions
ETL Grate - Hopper Bottom KIT0938
ETL Grate - Hopper Internal KIT0942
Pellet Cleanout Door KIT0954
Under Hopper PAL Rail Comp KIT1003
Under Hopper Filler Panel KIT0930
Lid Nameplate KIT0998

Replacement Instructions

Lid KIT0996

Replacement Instructions

Lid Bumper KIT1021 Replacement Instructions
Lid Handle KIT0997 Replacement Instructions
Lid Hinge KIT0928 Replacement Instructions
P.A.L. Rails Front Rail KIT0985
Front Rail Trim KIT0984
Left or Right Side Rail KIT0956 Replacement Instructions
Left Side Trim KIT0959

Replacement Instructions

Right Side Trim KIT0957 Replacement Instructions
Wheels Caster Wheel KIT0613



Power/Electric Service Parts

PART SKU REPLACEMENT INSTRUCTIONS
Controller Controller KIT1002 Replacement Instructions
Controller Knob KIT1012 Replacement Instructions
Motherboard N/A Replace auger box
Pellet Sensor & Wire Harness KIT0983 Replacement Instructions
Power Cord - Y cord KIT0999
Power Switch N/A Replace auger box
Electric Side Burner Burner KIT1001
Cover KIT1020
Wire Harnesses Hopper Wire Harness KIT0921 Replacement Instructions
Drivetrain Wiring Harness N/A Replace auger box



Mechanical/Internal Service Parts

PART SKU NOTES
Auger Auger Box KIT0936 Replacement Steps
Auger Bushing KIT0962 Replacement Instructions
Auger w/Bushing KIT0923 Replacement Instructions
Auger Motor N/A Replace auger box
Drip Tray KIT0978

Firepot

KIT0926 Replacement Instructions
Grates Main Grate - Lg KIT0976
Main Grate - Sm KIT0933
Upper Grate  KIT0982
Grease Management System Grease & Ash Keg KIT0963
Grease Chute KIT0979 Replacement Instructions
Ash Cap KIT0968
Heat Baffle KIT0980 Replacement Instructions
Hot Rod (Ignitor) KIT0927 Replacement Instructions
Induction Fan KIT0925 Replacement Instructions
Wired Meat Probe KIT0780
RTD KIT0929 Replacement Instructions

Hardware

PART SKU NOTES
Blister Pack 1/2 KIT1005

32- 1/4-20 x 3/4" screws
61-1/4 -20 x 1/2" screws
4- mounting plates
2- .375" washers
2- round Cotter pins
2- Clevis pins
2- 120° Cotter pins
2- silicone bumpers
1- 6" Phillips head screwdriver

Blister Pack 2/2 KIT1006
Phillips Screwdriver KIT0950 6" Phillips head screwdriver
1/4-20 x 3/4" Screws w/ washer KIT1011  x4 screws
1/4-20 x 1/2" screws KIT1010  x5 screws
