Woodridge Pro Support Guide

What's in This Article?

Model Number

The Woodridge Pro is an AC, WiFIRE-enabled grill.

Pro Lifestyle.png

Your support guide for the Woodridge Pro Traeger grill.

Buy your Woodridge Pro on traeger.com here:



MODEL NUMBER

COUNTRY STATUS

NOTES

TFB97JLH US & CA Active

Woodridge Pro.png

Features & Benefits - Talking Points

The Woodridge Series is designed to be the new entry point grill for Traeger. Careful care has been given to the Woodridge design so that it upholds the same quality that Traeger's premium grills are known for while being able to be set at a lower price, making it an affordable entry point for those looking to get into wood pellet grilling.

  • VALUE: Best price point per square inch of any grill in Traeger's lineup.
  • CAPACITY:
    Grill grate depth allows you to cook large cuts of meat like brisket or a Thanksgiving turkey. This is something other grills in the same price range sometimes can't accomplish.
    Woodridge_Lifestyle_Food on Grill_003.jpg
    • Increased space between main and upper grill grates: More space for users to flip burgers or turn chicken wings without worrying about bumping into the top rack.
      Other wood pellet grills claim high sq. in. cooking capacity, but that comes at the cost vertical real estate—often their tiers are so close together all you can cook on them is bacon or jerky.
  • TECHNOLOGY:
    • Full-color digital controller display with a dot-matrix display and capacitive touch buttons, which recognizes electrical signals from a user's finger and registers it to the touched area of the device.
    • Compatible with Traeger Wireless Meat Thermometers.
  • FUNCTIONALITY:
    • Free-flow firepot has holes in it to allow ash and sawdust to flow freely from the firepot into the grease and ash keg, the same as our premier line of touchscreen grills.
    • Drip tray has full coverage in the cooking cavity and has a steep slope, which helps prevent flare-ups that sometimes happen in other grills with drip trays that don't offer full coverage.
    • EZ-Clean Grease & Ash Keg features a keg cover (aka EmberShield or Ash Cap) to prevent residual sparks in the keg from flying up into the grill cavity and potentially starting a grill fire. The design allows for easy removal for cleaning and only one way to place it back in the grill, keeping installation simple.
      Woodridge Series-Ash cap.jpg
    • Staging hooks provide a place to hang grill grates when cleaning or when the upper grate isn't in use.

Pro hooks.png

  • TEMPERATURE ACCURACY:
    • Woodridge Series grills use a 3-inch RTD instead of a thermocouple. The RTD probe was perfected in Traeger's earlier grills, bringing the same temperature consistency as a thermocouple.

Differentiating Between Woodridge Series Models

The Woodridge Series consists of three models:

  • Woodridge Pro

Additional differences between the three Woodridge Series grills include:

  • Woodridge Pro has a folding side shelf and a bottom shelf.
  • Woodridge Elite has a cabinet and an electric side burner.
  • Woodridge Pro and Elite have a pellet sensor.
  • Woodridge Pro and Elite have two additional buttons on the controller: Super Smoke and Keep Warm. This is the first time Traeger is offering Super Smoke on a model under $1,000!

Woodridge Pro Facts and Features

Pro Facts and Features.png

Documentation

DOCUMENT LANGUAGE AMENDMENTS
Owner's Manual

English

French Canadian


Assembly Guide

English

French Canadian



Assembly

Using a Woodridge Controller

Woodridge Errors

Pro Dimensions.png

Specs

Controller Matrix LED WiFIRE Controller
Startup Procedure Closed-Lid
Assembled Dimensions

67" L x 27" D x 47" H

170.18cm L x 68.58cm W x 119.38cm H

Assembled Weight

190 lbs

86.18 kg

Package Dimensions

44" L x 30" W x 20" H

111.76cm L x 76.2cm W x 50.8cm H

Package Weight

230 lbs

104.32 kg

Main Grate Dimensions

31.8" L x 18.4" D

81cm L x 46.73cm D

Main Grilling Area

585 sq. in

1486 sq. cm

2nd Grate Dimensions

31.8 L x 12.1 D

#cm L x #cm D

2nd Grate Grilling Area

384 sq. in

975 sq. cm

Total Grilling Area

970 sq. in.

2463.8 sq. cm

Hopper Capacity

24 lbs

10.88 kg

Meat Probe Count 2
Side Shelf Folding
Exhaust System Downdraft
Pellet Evacuation Trapdoor
Pellet Sensor Yes
Super Smoke Yes
WiFIRE Yes
Country of Origin China

Pro Capacity.png

Compatible Accessories

Accessories Included with Purchase
The Woodridge Pro includes the following accessories with purchase.
ACCESSORY SKU QTY
keg liner - existing YOS liner fits
Add-On Accessories
ACCESSORY SKU MULTI-LINGUAL BUY ON TRAEGER.COM NOTES
Cover BAC775 BAC777   Full-length
SIOC: BAC776
Drip Tray Liner BAC818
Grease & Ash Keg Liner

BAC608

Grease & Ash Keg Liner

5 Pack

Meat Probe BAC431 Meat Probe (2 Pack) 2-Pack; Retail SKU
Wireless Meat Thermometer BAC785 Wireless Meat Thermometer

Charging dock and 1 probe included

P.A.L. Accessory Hooks BAC613 Pop-And-Lock Accessory Hooks 3 Pack
Cup Holder BAC707 Pop-And-Lock Cup Holder
Front Folding Shelf BAC760 Pop-And-Lock Folding Front Shelf
Roll Rack BAC614 Pop-And-Lock Roll Rack
Storage Bin BAC612 Pop-And-Lock Storage Bin
Pellet Bin BAC637 BAC615 StayDRY Pellet Bin & Lid



Service Parts

Pro Service Parts.png

1 Upper Grill Grate
2 Lower Grill Grate  11 Legs
3 ModiFIRE Grill Grate 12

Caster Wheels

4 Drip Tray
The drip tray for the Woodridge grill is designed to be placed in one direction to allow grease to flow into the grease drain. The size allows ample coverage to allow for large cooks.
13 Bottom Shelf
5 Heat Baffle
Like previous grills, the heat baffle will direct the flow of the heat from the firepot throughout the grill.
14 P.A.L. Pop-and-Lock Accessory Rails
6

Grease Chute
This is a removable piece of the grease management system. The shape of this piece allows for placement in one way only, which will prevent improper placement. It is removable for easy cleanup.

15 Lid Handle
7 EZ-Clean Grease & Ash Keg
The same EZ-Clean system from the Flatrock is in use on the Woodridge. This makes cleaning out the keg fast and easy. The same liners for the Flatrock EZ-Clean Grease + Ash Keg will fit.
16 Lid
Taking inspiration from newer grills like the Timberline and Ironwood, the Woodridge's new streamlined lid keeps smoke moving within the grill for convection cooking.
8 Ember Shield (aka Ash Cap)
The ember shield, also called the ash cap is new with the Woodridge Series. It sits atop the grease chute inside the grill to prevent sparks and embers from entering the Grease & Ash Keg.
17 WiFIRE Controller
The Woodridge controller has a new look. This WiFIRE-enabled Dot-Matrix controller displays information differently from previous WiFIRE-enabled models.
9 Wired Meat Probe
The same, trusted wired meat probe included with most Traeger pellet grills.
18 Auger Box
This all-new component is the biggest difference in serviceability that differentiates the Woodridge Series from Traeger's previous lines of grills. This single component houses the grill's primary mechanical components: the auger, auger motor, hot rod, Induction Fan, and control board
10 Folding Side Shelf 19 All-Terrain Wheels

Grill Body Service Parts

PART SKU NOTES
Backsplash Backsplash KIT0977 Incl. Hardware
Black; Steel; 240x834mm
Replacement Instructions
Backsplash Hooks KIT0960 Incl. Hardware
Black; Steel; 42x408mm
Replacement Instructions
Hopper  Hopper Cavity & Pellet Sensor KIT0981 Incl. Hardware
Black; Steel; 267x407mm
Replacement Instructions
Hopper Lid KIT0953 Incl. Hardware
Black; Steel; 506x363mm
Hopper-Grill Body Bracket KIT0943 x4; Incl. Hardware
Black; Steel; 25x59mm
Heritage Trim Band KIT0967

Piece between hopper and barrel
Black; Steel; 475x52mm
Replacement Instructions

ETL Grate - Hopper Bottom KIT0938

Grate underneath hopper
x2 pieces (1 big, 1 small); Incl. Hardware
Black; Steel

ETL Grate - Hopper Internal KIT0942 Grate inside hopper to protect from auger
Incl. Hardware
Black; Steel; 272x202mm
Replacement Instructions
Pellet Cleanout Door KIT0954 Incl. Hardware
Black; Steel; 107x87mm
Legs Leg KIT0945 x1; Incl. Hardware
Black; Steel; 690x65mm
Caster Wheel w/Brake KIT0986

Incl. Hardware
Black; Steel & PVC; 3"

Includes the wheel hooves

Wheel w/Axel & Feet KIT0946

x2 Wheels
Black; Steel & Plastic; 7"

Includes the wheel hooves

Wheel w/Cotter Pin KIT1009 x2
Black; Steel & Plastic; 7"
Bottom Shelf, Side KIT0970 Black; Steel; 457x558mm
Bottom Shelf, Center KIT0971 Black; Steel; 510x384mm. Weight limit= 3 bags of pellets (approximately 60lbs)
Lid Lid KIT0972 Incl. Hardware
Black; Steel; 297x871mm
Replacement Instructions
Lid Bumper KIT1021 x2
Black; Silicone Rubber; 18mm (length)
Replacement Instructions
Lid Handle KIT0973 Incl. Hardware
Steel; 91x635mm
Replacement Instructions
Lid Hinge KIT0928 x2; Incl. Hardware
Stainless Steel; 22x10mm
Replacement Instructions
P.A.L. Rails Front Rail KIT0985 Incl. Hardware
Silver; Steel; 62x865mm
Front Rail Trim KIT0984 Incl. Hardware
Silver; Steel; 102x797mm
Left or Right Side Rail KIT0956 Interchangeable between left & right sides
Incl. Hardware
Silver; Steel; 62x511mm
Replacement Instructions
Left Side Trim KIT0959 Incl. Hardware
Black; Steel; 102x517mm
Replacement Instructions
Right Side Trim KIT0957 Hopper side; Incl. Hardware
Black; Steel; 101x469mm
Replacement Instructions
Shelves Side Shelf Brackets KIT0974
Black; Steel; 512x369mm
Side Shelf KIT1000

Incl. Hardware

Black, Steel

Wheels Caster Wheel w/Brake KIT0986 Incl. Hardware
Black; Steel & PVC; 3"
Wheel w/Axel & Feet KIT0946 x2 Wheels
Black; Steel & Plastic; 7"
Wheel w/Cotter Pin KIT1009 x2
Black; Steel & Plastic; 7"



Power/Electric Service Parts

PART SKU NOTES
Controller Controller KIT0975 Dot Matrix LED; 120V; x2 Probe Jacks; Bluetooth-compatible
Replacement Instructions
Controller Knob KIT1013 Silver; 46x20mm
Replacement Instructions
Motherboard N/A Replace auger box
Pellet Sensor & Wire Harness KIT0983 Incl. Hardware
Black; Steel & Plastic; 220mm
Replacement Instructions
Power Cord KIT0257 120V, Detachable
Power Switch N/A Replace auger box
Wire Harnesses Hopper Wire Harness KIT0921 Incl. Hardware
Multicolor, 120V, 330mm
Replacement Instructions
Drivetrain Wiring Harness N/A

Replace auger box

Replacement Instructions



Mechanical/Internal Service Parts

PART SKU NOTES
Auger Auger Box KIT0936 Incl. Hardware & Auger Motor Pin
Black; Steel; 206x580x180mm
Replacement Steps
Auger Bushing KIT0962 Incl. Auger Motor Pin
White; Nylon; 22x38mm
Replacement Instructions
Auger w/Bushing KIT0923 Incl. Auger Motor Pin & Auger Bushing
Steel & Nylon; 35.5x194mm
Replacement Instructions
Auger Motor N/A Replace auger box
Auger Motor Pin N/A Pin included in other auger KITs
Drip Tray KIT0978 Steel; 414x795mm

Firepot

KIT0926 Incl. Hardware
120V; Steel
Replacement Instructions
Grates Main Grate - Lg KIT0976 Black, enamel-coated steel
467x513mm
Main Grate - Sm KIT0933 porcelain
467x288mm
Upper Grate  KIT0982 Black enamel-coated steel
327x803mm
Grease Management System Grease & Ash Keg KIT0963 Black, Steel and PA66 plastic
158x191mm
Grease Chute KIT0979 Stainless steel; 302x60x40mm
Replacement Instructions
Ash Cap KIT0968 Steel; 82x174mm
Heat Baffle KIT0980 Steel; 155x364mm
Replacement Instructions
Hot Rod (Ignitor) KIT0927 120V; 407mm
Replacement Instructions
Induction Fan KIT0925 Black; Plastic; 120V; 120x120mm
Replacement Instructions
Wired Meat Probe KIT0780 x1 wired meat probe
RTD KIT0929 Incl. Hardware
120V; White wire; 600mm
Replacement Instructions



Hardware

PART SKU NOTES
Blister Pack 1/2 KIT0987

24- 1/4-20 x 3/4" screws

75-1/4 -20 x 1/2" screws

4- mounting plates

2- .375" washers

2- round Cotter pins

2- Clevis pins

2- 120° Cotter pins

2- silicone bumpers

4- 1/4-20 shoulder screw

1- 6" Phillips head screwdriver

Blister Pack 2/2 KIT1007
Phillips Screwdriver KIT0950 6" Phillips head screwdriver
1/4 20 Screws w/ washer KIT1011 x4 screws
1/4 20 screws KIT1010 x5 screws
